VH-610

Specification
X TRAVEL:610 mm
Y TRAVEL:460 mm
Z TRAVEL: 510 mm
SPINDLE NOSE TO TABLE SURFACE :130 ~ 640 mm
TABLE SIZE: 800 x 450 mm
T-SLOT (Q'TY X SIZE X DIST) : 3 x 18 x 100 mm
MAX. TABLE LOAD:400 kg
CNC CONTROL:Fanuc/Mitsubishi/Siemens
Spindle
TRANSMISSION:Belt type
SPINDLE TAPER:BT-40
SPINDLE SPEED:10,000 rpm
SPINDLE MOTOR:5.5 / 7.5 kW
Other Items
ATC CAPACITY:ATC Genoa type 16 tools / Arm type 24 tools for maximum
Specification
X TRAVEL:24.02 inch
Y TRAVEL:18.11 inch
Z TRAVEL:20.08 inch
SPINDLE NOSE TO TABLE SURFACE :5.12 ~ 25.2 inch
TABLE SIZE: 23.62 X 12.6 inch
T-SLOT (Q'TY X SIZE X DIST) : 0.12 x 0.71 x 3.94 inch
MAX. TABLE LOAD:881.8 lbs
CNC CONTROL:Fanuc/Mitsubishi/Siemens/Heidenhain
Spindle
TRANSMISSION:Belt type
SPINDLE TAPER:BT-40
SPINDLE SPEED:10,000 rpm
SPINDLE MOTOR:5.5 / 7.5 kW
Other Items
ATC CAPACITY:ATC Genoa type 16 tools / Arm type 24 tools for maximum

*Spindle motor power depends on motor selection

*Note: Specifications are subject to change without further notice.
