MT-900


    • 5-Axis CNC Mill-Turn Machining

Capacity
Maximum swing :Ø500 mm
Maximum machining diameter :Ø300 mm
Maximum machining length:922 mm
Milling head
Tool shank type (milling/turning):BBT-30
Milling spindle speed:24,000 rpm(Built-in)
A-axis index:0.001°
Travel
X-axis:420 mm
Y-axis:±150 mm
Z-axis:900 mm
A-axis:360°
B-axis:±110°
C1-axis:360°
C2-axis:360°
W-axis:968 mm
B-axis
Rotary angle:360°
Index:1 Arcmin
Max. Spindle speed:4,000 rpm
C-axis
Rotary angle:360°
Index:0 Arcmin
Max. Spindle speed:3,000 rpm
Main/Sub-Spindle
Spindle nose type:A2-6
Chuck diameter:6"
Max. Spindle speed:3,000 rpm
Spindle bore dia.:Ø56mm
Draw Bar Dia.:Ø45mm
Front bearing I.D of spindle:Ø80 mm
ATC
Tool capacity:24 pcs
Max. tool length:150 mm
Max. tool diameter:Ø80 mm
Max. tool weight.:3 kg
T-T:4.8 sec
Turret
Type:Servo
Tool capacity:11 pcs
Square tool shank:20X20
Capacity
Maximum swing :Ø19.69 inch
Maximum machining diameter :Ø11.81 inch
Maximum machining length:36.3 inch
Milling head
Tool shank type (milling/turning):BBT-30
Milling spindle speed:24,000 rpm(Built-in)
A-axis index:0.001°
Travel
X-axis:16.54 inch
Y-axis:±5.91 inch
Z-axis:35.43 inch
A-axis:360°
B-axis:±110°
C1-axis:360°
C2-axis:360°
W-axis:38.11 inch
B-axis
Rotary angle:360°
Index:1 Arcmin
Max. Spindle speed:4,000 rpm
C-axis
Rotary angle:360°
Index:0 Arcmin
Max. Spindle speed:3,000 rpm
Main/Sub-Spindle
Spindle nose type:A2-6
Chuck diameter:6"
Max. Spindle speed:3,000 rpm
Spindle bore dia.:Ø2.21 inch
Draw Bar Dia.:Ø1.77 inch
Front bearing I.D of spindle:Ø3.15 inch
ATC
Tool capacity:24 pcs
Max. tool length:5.91 inch
Max. tool diameter:Ø3.15 inch
Max. tool weight.:6.61 lbs
T-T:4.8 sec
Turret
Type:Servo
Tool capacity:11 pcs
Square tool shank:0.79X0.79
